Camera

Product Name

3.0 Megapixel IP 180 Degree Panoramic Camera

Model No.

HB-IP180NIR

DSP

high performance MStar335+317

Imaging Sensor

1/2.9" CMOS Sensor

Resolution

3MP

Lens

180degree lens

IR LEDs

12PCS

Night Vision Distance

15m

Video

Video processing

H.265/H.264 video compression, dual streaming, AVI format, 0.1M~6Mpbs adjustable;

Video Output

Main stream:[email protected],1920×1080,1280×960,1024×768,1280×720
Sub Stream:960×540,640×360,480×270,352×288,320×240

Frame rate

3.0MP 25 frame,support 1~25frame/seconds adjustable

Illumination

Color [email protected],B/W0.01 [email protected]

D/N Mode

IR-CUT Auto switch

Network and Function

Network Interface

RJ45 ethernet ,10/100 M adaptive;support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPNP etc.protocol

Access Protocol

Spoort Standard ONVIF protocol, support third-party access;Support Smart phones; support Android system, iPhone platform

Motion Detection

support motion detection,IO alarm linkage front-end storage device

Remote Control

Support uniform client and platform system application

SDK

Supply complete SDK for second development.

POE

YES (optional)
IEEE802.3at/af Standard
PoE/IN:37-57V(15.4W)
DC/OUT:12V/1A(12.95W)

Playback

Support front end storage ,playback and download

WEB configuration

Support WEB configuration, OSD, real-time video transmission

Common

Power

12VDC(±10%)/POE

Operating Temperature and humidity

 -40℃ ~ 85℃, humidity is less than 95% (no condensation)

Dimension

120x62

Weight

0.42kg
